Please see Specs Sheet tab for product dimensional specifications
Features:
- Design saves precious space through use of bowl partitions
- Custom style fabricated bowl for true gauge integrity
- All sinks have a 3/4in radius at all intersecting planes
- Stainless steel gussets are machine welded 360 degree to a stainless steel triangular plate
- Gusset plates are fully welded directly underneath the sink for support
- Polished to a # 4 blended finish
- Legs: 1 5/8in O.D 16 gauge stainless steel complete with 1in adjustable impact resistant plastic feet
- Sink hemmed on the roll and backsplash to eliminate cuts from rough edges
- Supplied with stainless steel drain basket and strainer
- Space saving design eliminates 4in of length through the use of bowl partitions
Specifications:
- Material: 16 gauge 304 stainless steel bowl, 430 body
- Water supply: 1/2in hot and cold
- Legs height: 18.50in
- Bowl depth: 14in
- Faucet hole: 8in o.c. (faucets not included)
Note: This product is also available in Delux: 16 gauge 304 stainless steel and Aerospec: 14 gauge 304 stainless steel. If you have any questions please contact our Customer Service Department at 877-706-4480 or Ask the Pros prior to placing an order.
Please refer to table below and see Options tab above
Option | Bowl Width | Bowl Length | Unit Width | Unit Length | Cubic Feet | Faucet Holes | Ship Weight |
A | 18 | 14 | 24 | 47.5 | 14 | 1 | 85 |
B | 18 | 16 | 24 | 53.5 | 16 | 1 | 95 |
C | 18 | 18 | 24 | 59.5 | 17 | 1 | 110 |
D | 18 | 20 | 24 | 65.5 | 19 | 2 | 122 |
E | 18 | 24 | 24 | 77.5 | 23 | 2 | 134 |
